The Core
All Qu-5/6/7 Mixers Include:
• 96kHz FPGA Processing
• 38 Inputs to Mix (32 Mono/Linkable, 3 Stereo)
• DEEP Processing Ready
• 12 Mixes (6 Mono/Linkable, 6 Stereo) + LR
• 4 Mono/Linkable Matrix
• 6 Stereo FX Engines + Dedicated Returns
• 128×128 Intelligent SLink Port for Everything I/O
• 32×32 USB Audio Interface
• 8 SoftKeys
• AES Output
Processing & FX
- 96kHz XCVI Core
- 6 Multi-FX Engines with dedicated Stereo Returns
- DEEP Processing Ready
Mix Architecture
- 38 Inputs to Mix (32x Mono/Linkable, 3x Stereo)
- 12 Mixes (6 Mono/Linkable Aux/Group, 6 Stereo Aux/Group)
- 4 Mono/Linkable Matrix
- Stereo Main LR Output
I/O
- 32 XLR/Jack ‘Combi’ Mic/Line Input Sockets
- 2 Stereo Line Input Sockets (each 2x TRS)
- 20 XLR Output Sockets
- 1 XLR Talkback Socket
- 2 TRS Output Sockets
- 1 AES3 Stereo Digital Output Socket
- 128×128 Intelligent SLink Port for Everything I/O expansion and system connections
- 16×16 48/96 kHz Dante interface with dedicated locking EtherCon port (Qu-7D only)
- Stereo Headphone Output
Control
- 7” Capacitive Touchscreen
- 33 100mm Motorised Faders
- 4 Channel Strip Layers
- Remote control via free apps – Windows/MacOS/iOS/Android
- 8 SoftKeys
- Configurable single/dual Footswitch Connection
Recording & Playback
- USB-A For stereo audio record/playback and data transfer
- USB-C Audio interface for multichannel record/playback (32×32)
- SD Card Slot for multichannel audio recording or playback (16×16@96kHz, 32×32@48kHz)
Misc
- 12V Lamp Socket
- Configurable Chromatic Channel Meter LED’s
